Shure | QLXD4

Shure | QLXD4

In the box: PS24 Power supply, 2 1/2 Wave Antenna, 2 BNC Cable, 2 BNC Bulkhead Adapter, Rackmount Kit, Rackmount Bracket-Long, Rackmount Bracket-Short, Link plate & 4 Receiver Rubber Feet.

Digital wireless receiver combines professional features with streamlined set-up and operation. Features include Automatic Channel scan, Networked Channel Scan, digital predictive switching, and AES 256 encryption for security.

• Automatic Channel Scan quickly finds clear frequencies; Networked Channel Scan then shares open frequencies between multiple receivers over Ethernet, with one touch syncing
• Digital Predictive Switching Diversity ensures a stable RF connection
• Highly efficient RF spectrum usage – up to 22 transmitters per 8 MHz channel
• Secure AES 256 bit encryption of all wireless transmissions
• Shure Wireless Workbench® software allows remote control from PC or Mac
• ShurePlus™ Channels mobile app allows remote control from iOS devices
• Half rack format with detachable ½ wave antennas
• Up to 60 dB of adjustable audio gain
• Up to 72 MHz tuning bandwidth (region dependent)
• More than 60 pre set compatible channels per frequency band (region dependent)
• High contrast LCD menu and controls with lockout feature, plus Audio and RF LED meters with peak indicator
• Mic / line switchable XLR output, and 6.3 mm instrument output
• Durable aluminium construction with brushed finish

• Product series: QLX-D
• Usage environments: Theater Stage
• Optional accessories: UA221
• Component: Wireless receiver
• Receiver types: Single
• Frequency band: G51 (470–534 MHz), H51 (534-598 MHz) or K51 (606-670 MHz)
• Bias via BNC: No
• Dante audio network interface: No
• Network ability: DHCP, link-local, static
• Antenna cascade: No
• Line mic switch: Yes
• Image rejection: 70
• Phantom power protection: Yes
• Media control system connection: No
• Connector: 3 Pin XLR
• Included power supply: EU
• Color: Black
• Logic output: False
• On/Off switch: Yes
• Mute switch: No
• Status indicator: LED
• Weight: 777 g
• Width: 197 mm
• Height: 41 mm
• Depth: 151 mm
