CLF | Stinger

CLF | Stinger

The Stinger is a feature-packed moving head. 36 RGBW, pixel controllable, high output LEDs provide many creative possibilities. A 6° punchy beam angle ensures impressive mid-air effects. The additional 49 CW LED star effect and the reflector module on the backside make the Stinger the ultimate multi effect LED fixture. Matrix effects can be controlled by Art-Net.

All features come in a rugged and touring-proof housing which can move continuously. The fixture can be rigged in any position by using the supplied omega bracket.

Features

• 6° Beam angle
• Continuous movements
• Individual controllable LEDs
• Star effect
• Art-Net controllable pixel effects
• Reflector module on backside
• Low noise controllable fan

• Length: 466mm
• Width: 246mm
• Height (head vertical): 575mm
• Net Weight: 20 KG
• Color: 36 individually controllable RGBW LEDs
• Color Macro Effects: Yes
• Star Effect: 49 individually controllable CW LEDs
• Star Macro Effects: Yes
• Shutter: Variable 0 – 100%, random, pulse
• Dimmer: 0 – 100%
• Source: 36 x RGBW LEDs + 49 CW LEDs
• Beam Angle: 6°
• Power: Powercon in and out
• Data: 3 & 5 pin locking XLR, RJ45
• Output: 25800 lx @ 5M
• Settings: LCD display
• Protocols: DMX512, RDM, Art-Net
• Channels: 21 / 22 (DMX) + 144 (Video) / 166 / 206
• Updates: By DMX Link
• Mounting: Omega brackets
• Orientation: Any
• Protection Rating: IP20
• Safety: Attachment point
• Pan: Infinite
• Tilt: Infinite
• Resolution: 16 bit
• Minimum Ambient Temperature: 0°C
• Maximum Ambient Temperature: 35°C
• Cooling: Low noise controllable fan
• Input: 100-240 V, 50/60 Hz
• Power Consumption: 580W
• Approvals: CE compliant
• Included Items: User Manual, Power cable, DMX cable, Omega bracket
• Ordering: CLF Stinger – 160110
