The TD44 Tower makes for an excellent vertical truss that allows the safe, quick lifting of regularly loaded horizontal HD/FD44, FT, XT and TT Truss Rig and Roofs to their service height. In terms of static, the TD44 Tower is designed for a high flexural- and pressure strain.

Especially due to a roof this high, flexural strain is required.

Features

• Steel base equipped with high quality cast wheels
• Build for extreme heights and loads
• Up to 16 meters (52ft.)
• Multifunctional Top Part for use with manual and motorized hoists

Top section & Sleeve Blocks
A new multifunctional top part for use of manual chain hoist as well as motorized hoist has been redesigned and built stronger.

Standard sized XTS and TT corner blocks with usage of 2 bolted sleeve plates guarantees a perfect geometric rig. These blocks make it possible to fit the TT / XTS / FT50 Truss to all four sides

mby using bolted receivers. The upper sleeve plate is equipped with an integrated hanging point. The standard FD44 sleeve blocks have predesined welded receivers on 3 sides for attachments of XD/ST or FT50 truss.

Hinge set
A strong, safe and cost effective solution to erect the TD44 Tower. The hinge sets are 100mm long. Those half connectors with a hinge fork allow a very high vertical load. 4 Hinge sets (2 left and 2 right) are required per tower.

Base section & Outriggers
Steel Base on wheels available with short outriggers and long outriggers in combination with stabilizer bars.

• Maximum height: 16 m (53 ft)
• Maximum load: 2000 kg (4400 lbs)
• Tower truss: TD44
• Compatible sleeve blocks: TTU, TTS, TT, XTS, FT50, ST, XD, FD/HD44
