Epson - EB-L30000U - Projector with Interchangeable Lens

Epson - EB-L30000U Projector

The compact 30,000 lumen 3LCD projector for demanding installations that require the highest levels of brightness.

The EB-L30000U Pro AV installation projector has been developed for vivid theatrical and film projections, or areas with high ambient light, such as shopping centres and galleries. Its compact design is a significant customer benefit for storing, handling and shipping.

The brightest projection
At 30,000 lumens, this is Epson's brightest ever Pro AV projector. This enables users to create powerful presentations and totally immersive experiences.

Compact design
Its more compact design means it can fit into smaller spaces which makes it easier for users to transport, install and store.

4K compatible lenses
Epson offers a concise range of different lenses that produce crisp, high-definition images even when projecting at a distance. This installation projector also features Epson's 4K Enhancement Technology, which uses pixel shifting to double the resolution as a more cost effective option to producing 4K content. The EB-L30000U is supplied without a lens as this allows the user to chose the most appropriate lens or lenses for their needs. All EB-L25000U lenses are compatible with the EB-L30000U

Mechanical shutter
The mechanical shutter is particularly useful in theatres for creating backdrops. The projector can be turned to black instantly with a simple switch, and on again when required. This feature is very important in rental and staging events, where laser lights are being used, to protect the lens from laser damage.

Key Features

Epson's brightest ever
At 30,000 lumens, this is Epson's brightest ever Pro AV projector.

Compact design
Easy to transport, install and store

Lens flexibility
Allows users to chose the most appropriate lens for each project

4K Enhancement Technology
Epson's 4K Enhancement Technology means crisp, high-definition images

Enhanced protection
The mechanical shutter protects the lens from laser strikes

Technology

• Projection System: 3LCD Technology, RGB liquid crystal shutter
• LCD Panel: 1,43 inch with C2 Fine


• Colour Light Output: 30.000 Lumen- 20.000 Lumen (economy) In accordance with IDMS15.4
• White Light Output: 30.000 Lumen - 20.000 Lumen (economy) In accordance with ISO 21118:2012
• Portrait Colour Light Output: 30.000 lm
• Portrait White Light Output: 30.000 lm
• Resolution: WUXGA, 1920 x 1200, 16:10
• High Definition: 4K enhancement
• Aspect Ratio: 16:10
• Contrast Ratio: Over 2.500.000 : 1
• Native Contrast: 3.500 : 1
• Light source: Laser
• Laser Light source: 20.000 Hours Durability High, 30.000 Hours Durability Eco
• Keystone Correction: Manual vertical: ± 45 °, Manual horizontal ± 30 °
• Colour Video Processing: 10 Bits
• Colour Reproduction: upto 1.07 billion colours

Optical

• Zoom: Motorized
• Lens: Optical, varies by lens
• Lens Shift: Motorized - Vertical ± 65 %, horizontal ± 30 %
• Lens position memory: 10 positions
• Screen Size: 100 inches - 1.000 inches
• Projection Lens Focus: Motorized, varies by lens
• Offset: varies by lens
• Interchangeable Lens: Yes
• Standard Lens: Not included

Connectivity

• Interfaces: USB 1.1 Type A, USB 2.0 Type B (Service Only), Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11b/g/n (optional), VGA in, VGA out, DVI in, BNC in, HDBaseT, HD-SDI, HDMI (HDCP 2.2)
• Epson iProjection App: Ad-Hoc / Infrastructure

Advanced Features

• Security: Security bar, Control panel lock, Password lock, Wireless LAN security, Password protection
• Features: 4K enhancement, Absolute Black, Auto Calibration, Frame interpolation, Long light source life, Super resolution
• Video Colour Modes: Cinema, Dynamic, Natural, Presentation, DICOM SIM, Multi Projection, BT709
• Projector control: via: AMX, Crestron, Extron XTP

General

• Energy Use: 2.325 Watt, 1.511 Watt (economy), 0,5 Watt (standby), On mode power consumption as defined in JBMS-84 1.748 Watt
• Heat Dissipation: 7.905 BTU/hour (max)
• Supply Voltage: AC 200 V - 240 V, 50 Hz - 60 Hz
• Product dimensions: 790‎ x 710 x 299 mm (Width x Depth x Height)
• Product weight: 63,8 kg
• Noise Level: Normal: 49 dB (A) - Economy: 41 dB (A)
• Temperature: Storage -10° C - 60° C
• Humidity: Operation 20% - 80%, Storage 10% - 90%
• Included Software: EasyMP Monitor, iProjection
• Options: Wireless LAN unit
• What's in the box: HDMI Cable Clamp, Power cable, Remote control incl. batteries
• Room Type / Application: Large Meeting Room / Auditorium, Projection Mapping, Rental / Staging, Visitor Attraction
• Positioning: Ceiling Mounted, Flying Frame
• Colour: Black

Other

• Warranty: 60 months Carry in or 20.000 h
