CLF - Odin

The Odin combines cutting-edge LED technology, excellent light quality and a sturdy outdoor housing. Designed for high-demanding applications it comes with an outstanding optical system which ensures even light and color projection. The fixture comes with a fast and accurate zoom function which ranges from 11° to 50°. The IP65 rating makes is suitable for indoor and outdoor usage.

The RGB+Lime LED engine generates a rich color set, from vivid and saturated colors to subtle pastels. Adding lime fills the gaps between red, green, blue and enhances the color spectrum of the fixture. It also adds beautiful white tones to the feature set. The on-board, high performance LEDs deliver a high CRI value. Most striking is a high R9, which makes the Odin perfect for making skin tones look more healthy and natural.

Packed in a signature CLF housing, the Odin combines convection cooling with an ultra-quiet intelligent fan. The fixture can be aimed easily by using the one button test function. The fixture can also be configured for exhibition applications by using the configurable user modes. All in all, it is the ultimate workhorse for applications where superior lighting quality is required.

Key features:

  • Smooth RGB+Lime color mixing
  • IP65 rating
  • 11-50° zoom range
  • High CRI & R9 values
  • Silent operation
  • Definable user modes

Power:

  • Input voltage & rate: 100-240 VAC, 50/60Hz
  • Standby power: 10W
  • Nominal total power consumption  (at nominal voltage 230V): 262W
  • Typical current (at nominal voltage 230V): 1.2A
  • Cos φ: 0,994
  • Power plug type: PowerCON TRUE 1

Configuration:

  • LED color: RGBL
  • LED color temperature: 2500K-10000K
  • LED CRI level: <90
  • Quantity of LED: 12
  • Dimming frequency: 600-10000Hz
  • Dimmer resolution: 16 bit

Optical:

  • Beam angle: 11° – 50°
  • Output @ 1M
     Output @ 5M

Heat management:

  • Cooling type: Intelligent fan
  • MAX ambient temp (Ta max): 40°C
  • MIN ambient temp  (Ta min): -20°C
  • MAX housing temp. (ta=25°C): 45°C
  • MAX housing temp. (ta=40°C): 56°C

Menu:

  • Auto program: Yes
  • Static color: Yes
  • Manual calibration: Yes
  • Factory calibration: Yes
  • Strobe speed: 0-25Hz
  • Random strobe: Yes

Control:

  • DMX channel range: 6/8/9/13 ch
  • RDM: Yes
  • RDM Compliance: ANSI/ESTA E.120
  • W-DMX: Optional
  • sACN: No
  • DMX input connection: DMX 5 pin in & out (3 pin optional)
  • Data input connection: No

Hardware:

  • Interface: LCD display
  • Software upload method: XLR (via special box)
  • Safety attachment point: 2

Installation:

  • Location: Indoor/outdoor
  • IP rating: IP65
  • Orientation: Any

Physical:

  • Net product weight: 6 KG
  • Machine dimensions: – length: 314mm
  • Machine dimensions – depth: 253mm
  • Machine dimensions – height: 363mm
  • Item number: 156360
  • Included items: Power cable, manual
  • Optional accessories: Barndoor, snoot
  • Approved certifications: CE, RoHS, MET pending
More Information
Condition New
Brand CLF Lighting
