PATENTED OPTICS

Our internationally patented optical system optimizes the LED source. The reflector design in combination with a Fresnel lens gives us the highest optical efficiency in the industry. De Sisti is able to achieve similar outputs to our competitors with half the power requirements. Our Super LED Fresnels produce the exact light you’ve come to expect from a traditional Fresnel.

GLASS FRESNEL LENS D

de Sisti utilizes a true Fresnel lens made of high quality, shock resistant borosilicate glass. Plastics lenses may discolor over time negatively affecting both output and color temperature. Glass is consistent, resilient to heat and offers better uniformity in beam protection.

SILENT OPERATION, WITH THE RIGHT TEMPERATURE

We use Self Stabilizing Silent Active Cooling technology. The speed of the fan is managed by an internal thermal sensor and CPU, automatically adjusting the temperature of the LED Array to 65°. The hydro dynamic bearing fan operates silently with a very low RPM. A unit must always be silent when it operates, not only with the fans switched off.

HIGH COLOR QUALITY OF LIGHT

You can expect the highest color quality from the De Sisti Super LED Fresnels with CRI & TLCI values above 95 throughout the rsnge. The result ensure maximum compatibiity of the light emitted by the devices with optical cameras that have no need for further adjustments.

UNIVERSAL PSU

De Sisti Super LED Fresnel are ready to use around the world with auto sensing power supplies accepting voltages from 90-250 volts.

Specifications

• Power to LED: 400W, DC Current to the LED (no flicker)
• Rated Voltage & PFC: 90-250V 50-60Hz PFC 0,96
• Power Connection: powerCON IN & OU
• DMX Data linkUSITT DMX512-A: 5-pin XLR for DMX in & out.Use shielded data cables.Do not overload the daisy chain. Up to a maximum of 32 devices can be used on a single DMX chain.
• DMX Channels: 1 at 8bit: Dimmer, 2 at 16bit: Dimmer
• LED ARRAY Lifetime: 50.000 hours with 70% Lumen Maintenance. The LED ARRAYS are tested and certified up to LM80
• CCT T: 3.200°K, D: 5.600°K
• CRI / TLCI T: 97 / 96, D: 96 / 97
• Protection Type: IP 22
• Max. Housing Surface, Temperature: 70° C
• Weight of Fixture: M.O. 20 kg. (44 lbs), P.O. 21,5 kg. (47,3 lbs)
• Weight of barndoor: 4 leaf 1,85 Kg (4.08 lb), 8 leaf 2,1 Kg (4.63 lb)
• Weight of color frame: 0,50 kg.
• Barndoor ring diameter Seat: 402mm / 15 4/5”, Accessory: 399mm / 15 2/3”
• Size of scrims & color frame Seat Diameter: 395 mm., Accessory Diameter: 393mm ( 15” 1/2)
• Lens diameter: 350mm / 14”
