NovaStar | ET4S-G(A4) - Media Server

NovaStar | ET4S-G(A4) - Media Server

The ET4S-G is a brand new media server developed by NovaStar, which is specifically designed for multimedia
exhibition halls, banquet halls, stage performances and other creative fixed installation scenarios. The ET4S-G
provides an excellent pixel-to-pixel display with ultra-high definition, diversified mosaic creativity and outstanding media arrangements for professional stage performances. Built-in with intuitive and user-friendly media playback and control software, the ET4S-G enables simplified stage display management and best-in-class human-machine interaction.

• Chassis: 4U
• Memory Size: 128G (DDR4)
• CPU: Dual Intel Xeon Gold Processor
• Storage: 1TB M.2 SSD (System Driver), 960GB U.2 SSD (Storage Driver)
• Graphics Card Model: 2× HPG4000, 1× MPGT400, 1× Sync Card
• Loading Capacity: 12× 4096×2160@60Hz
• Decoding Capacity: 2 layers of 8K@60 or 8 layers of 4K@60
• Program Quantity: Unlimited
• Layer Quantity: 12 layers (24 layers with 2 graphics cards, 36 layers with 3 graphics cards, 48 layers with 4 graphics cards) and 1 audio layer, with supported for expandability
• EDID Lock: ✓
• Cascading: ✓
• Frame Synchronization Splicing: ✓
• Dual-machine Backup: ✓
• iPad Control: ✓
• Protocol Control: ✓
• Operation System: Windows 10 Enterprise LTSC
• Software: Kompass FX3 (Dongle Included)
• Media Type: Video, audio, picture, subtitle, PPT, web page, NDI, streaming media, collection playback, capture card, digital clock, sequence frame
