NovaStar | ET1S-500G - Media Server

The ET1S-G is a new media server designed by NovaStar for small-scale LED or LCD fixed installation applications. It not only boasts high-quality, ultra-high-resolution pixel-to-pixel display capabilities but also offers diversified mosaic
creativity and outstanding media arrangements for professional stage performances. Built-in with intuitive and userfriendly media playback and control software Kompass FX1, the ET1S-G simplifies stage display management and
provides best-in-class human-machine interaction. It is ideally suited for exhibitions, showrooms, small-scale
conference rooms, and a variety of creative display applications.

• Chassis: 1U
• Memory Size: 16G (DDR4)
• CPU: AMD Ryzen 5600H
• Storage: M.2 SSD 500GB
• Graphics Card Model: Integrated Graphics
• Loading Capacity: 4096×2160@60Hz
• Decoding Capacity: 1 layer of 4K@60 or 4 layers of 2K@60
• Program Quantity: Unlimited
• Layer Quantity: Up to 4 layers and 1 audio layer
• EDID Lock: ✓
• Cascading: ✓
• Frame Synchronization Splicing: ✗
• Dual-machine Backup: ✗
• iPad Control: ✓
• Protocol Control: ✓
• Operation System: Windows 10 Enterprise LTSC
• Software: Kompass FX1
• Media Type: Video, audio, picture, subtitle, PPT, web page, NDI, streaming media, collection playback, digital clock
