RGBlink - M2S
RGBlink - M2S

RGBlink - M2S

Starting at

€75.00 Excl. Tax
was
€202.22 Excl. Tax

Availability:
View configuration
Art. code
BUNDLE-RG-M2S

RGBlink - M2S

Including:

  • 3 pieces EXT fitted
  • HDMI PGM&PST, PVW/Tally Module
  • 2 SDI Outputs
  • Flightcase

Input modules sold separately.

Ideal for meeting and conference spaces or applications, M2 (CP3072pro) provides not just live hands on controls for for live video presentation, but also full output scaling capabilites essential for modern display applications.

Up to nine individual inputs may be fitted for the ultimate in flexibily. All signals are synchronised and converted for output. Standard with four HDMI outputs, M2 output is multi-mode too, whether for conventional PST/PGM operations, dual 2K (4K1K) or 4K.

On board features include mutliple PIP window layers with layer effects mask, soft edge blend, Chroma Key available. LOGO and STILL layers for channel or programme logo are avaialble too. A wide range of transitiion effects to Program maybe utilised whether for timed TAKE or the via the T-Bar . M3 offers a unique independent TAKE feature for OSD text such which may be subtitles or other messaging loaded by USB.

Presets may be saved and recalled on demand and settings exported for backup or later use, and Genlock Y In and TALLY features are built in too.

Connectors

Input

3 slots, up to 9 inputs, Select from

DVI Module

HDMI Module

DP Module

SDI Module

VGA Module

CVBS Module

USB Module

1 x DVI-I

2 x HDMI-A (1 In | 1 Loop)

1 x DisplayPort

2 x BNC (1 In | 1 Loop)

1 x VGA

2 x BNC (1 In | 1 backup)

2 x USB 2.0 (1 In | 1 backup)

Output

M2

M2s

Standard with

HDMI

4 x HDMI



Standard with

HDMI

4 x HDMI-A

Optional SDI Module

SDI

HDMI

2 x BNC

2 x HDMI

Preview

HDMI | VGA

1 x HDMI-A | 1 x DSUB15

Communication

Tally

LAN

RS232

USB

Genlock

2 x DSUB15

1 x RJ45

1 x RS232

1 x USB

1 x BNC

Power

1 x IEC

Performance

Input Resolutions

SDI

SMPTE

480i | 576i | 720p@50/60 | 1080i@59.94/60 |1080p@23.98/24/25/29.97/30/50/59.94/60 | 1080psf@23.98/24/25/29.97/30

DVI | HDMI | USB

SMPTE

480i | 576i | 720p@50/59.94/60 | 1080i@50/59.94/60 | 1080p@50/59.94/60

VESA

800x600@60 | 1024x768@60 | 1280x720@60 | 1280x800@60 | 1280x960@60| 1280x1024@60 | 1400x1050@60 | 1600x1200@60 | 1920x1080@60 |2048x1152@60

VGA

VESA

800x600@60 | 1024x768@60 | 1280x720@60 | 1280x800@60 | 1280x960@60| 1280x1024@60 | 1400x1050@60 | 1440x900@60 | 1600x1200@60

CVBS

SMPTE

480i | 576i

Output Resolutions

Select from below or customized

HDMI

SMPTE

480i | 576i | 720p@50/59.94/60 | 1080i@50/59.94/60 | 1080p@50/59.94/60

VESA

800x600@60 | 1024x768@60 | 1280x768@60 | 1280x1024@60 |1600x1200@60 | 1920x1080@60



Supported Standards

SDI

SMPTE 425M (Level A & B) | SMPTE 424M | SMPTE 292M | SMPTE 259M-C | DVB-ASI

HDMI

DVI

DisplayPort

VGA

USB

1.3

S-DVI

1.0

UXGA

2.0

Power

Input Voltage

AC 85V~264V, 50/60Hz

Max Power

120W

Environment

Temperature

0℃~55℃

Humidity

10%~90%

Physical

Weight

Net(device)

14.6kg

Packaged

27kg

Dimensions

Net(device)

462mmx406mmx170mm

Packaged

610mmx580mmx395mm

More Information
Condition New
