Aurora - RXS-1

Aurora - RXS-1

Introducing the all-new RXS-1, the solution to your AV over IP control needs. Loaded out of the box with Aurora’s own IPBaseT Pro Server control software and the new, lightweight ReAX™ control engine. Powered by Linux, the RXS-1 All-In-One control system comes packed with an Intel® Core i5 processor, 8GB RAM, an 128GB SSD, and a 3-year warranty.

The RXS-1 is designed to interface with Aurora’s AV over IP line of transceiver products. Seamless integration with the VLX and IPX product lines allows for easy setup and faster installations.

• ReAX™ Control Engine
• IPBaseT Manager Pro Control Software
• 2 HDMI Outputs
• Two 1Gbps LAN ports
• Four USB 2.0
• Four USB 3.0
• Fiber Optic Audio Output
• Mic Input
• Speaker/Line Out
• Integrated Wi-Fi
• SD Card
• Linux OS
• Intel i5 Processor
• 128GB SSD
• Fanless Design

Technical

• Processor: Intel® Core i5-5200U 2.2GHz Dual Core
• Memory: 8GB RAM
• Storage: 128 GB SSD + SD Card Slot
• Graphics: Intel® HD graphics 5500 graphis card (32-bit color depth)
• HDMI: Two HDMI 4K30 4:4:4
• Audio: Mic, Speaker/Line, Optical
• Wi-Fi: 300M Internal
• USB 2.0: 4 Type A
• USB 3.0: 4 Type A
• LAN: Two 1G RJ-45

Mechanical

• Housing: Metal Enclosure
• Dimensions [L x W x H]: 22.4 x 17.7 x 4.9cm (8.81" x 6.96" x 1.92")
• Weight: 1.66kg (3.66 lbs.)
• Mounting: Desktop horizontal or vertical
• Power Supply: 12V 5A DC
• Power Consumption: 60 Watts Max
• Operation Temperature: 0 - 40 Celsius­ [32 ~ 104 Farenheit]
• Storage Temperature: -20 - 60 Celsius [-4 ~ 140 Farenheit]
• Relative Humidity: 20 ~ 90% RH [no condensation]
