Neutrik | NLT8MX-BAG - SpeakON 8 connector Male
Neutrik | NLT8MX-BAG - SpeakON 8 connector Male

Neutrik | NLT8MX-BAG - SpeakON 8 connector Male

List price:
€22.95 Excl. Tax
Your price:
€21.80 Excl. Tax
Your discount: 5%
Last stock:
6 pieces
Art. code
NE-81.0053

Neutrik | NLT8MX-BAG - SpeakON 8 connector Male

8 pole male cable connector, black-chrome metal housing, chuck type strain relief, ¼" flat tabs.

The speakON STX Series was especially designed for heavy duty amplifier-loudspeaker applications like professional touring. The extremely rugged and durable STX Series features an all metal housing.

Features

  • Current rating 40 A continuous, 50 A audio signal with 50% duty cycle
  • Robust and durable all metal housing
  • Reinforced metal quick lock system for ease and precise locking
  • Extra large solder contacts for up to 6 mm² (AWG10) wires
  • Mate with all available speakON products
  • Title: NLT8MX-BAG

Electrical

  • Contact resistance: < 2 mΩ (after lifetime)
  • Dielectric strength: 4 kVdc (peak)
  • Insulation resistance: > 10 GΩ
  • Rated current per contact: 40 A rms continuous
  • Rated current per contact: 50 A audio signal, duty cycle 50%
  • Rated voltage: 250 V AC
  • Attention: speakON is NOT to be used as an AC mains or power supply connector!

Mechanical

  • Cable O.D.: 8 - 20 mm
  • Cable retention: ≥ 220 N (subject to cable O.D. and material)
  • Lifetime: > 5000 mating cycles
  • Wiresize: 6 mm² / 10 AWG
  • Wiring: flat tabs for 1/4'' (FASTON® 6.3 x 0.8 mm) or soldering

Environmental

  • Temperature range: -30 °C to +80 °C
More Information
Brand Neutrik
