GeoBox - G802 - Edge blending processor

G802 is a dual channel professional curved screen edge blending processor designed for sophisticated edge blending as well as image warping, stacking, projection mapping…etc.

4 inputs (2x HDMI, 1x DP, 1x VGA) and 2x HDMI outputs are designed in G802. Input supports up to 4096*2160 @60Hz, 7680*1200 @60Hz with 4:4:4 full color sampling. Output supports up to 2048*1080 @60Hz. It is integrated with 10-bit high end processor, motion adaptive de-interlace, low angle smooth algorithm, 3:2/2:2 pull-down and supports non-VESA standard input timing

Advanced warp technology is embedded in G802. User can perform sophisticated geometry alignment and curved screen edge blending through remote controller, WebGui, USB or Ethernet. Maximum geometry control point is 17x17 grids. Linearity Grid Line Adjustment and Corner Wall image adjustment for mapping image at 90 degrees corner is a new function in geometry alignment. Separate RGB gamma correction for edge blending color fine-tune, individual color correction for each output, fine pixel color uniformity and 9 regions nonedge blending area black level uplift are also embedded in G802. Users can see real time geometry and colour adjustment to get optimized result.

HDMI 2.0 loop out supports daisy chain connection up to 7680*1080 @30Hz and allows large display with multiple units cascaded. Video wall function in G802 is to crop and allocate source image for each projector and set overlap pixels for edge blending. Complete curved screen edge blending can be achieved through remote controller or Ethernet without PC software, video distributor and splitter.

G802 is designed to support programmable EDID and non-VESA standard input. User can create any EDID timing in the range between 1024x768 and 3840x2400 in order to optimize video performance. Using G802, users can replace high end projector with low cost projector without lens shift, warp and edge blending. It provides easy configuration, low entry barrier, cost effective, reliable and flexible solution.

Dual power supply system is embedded in G802. User can use either AC power 100V-240V power supply or DC 12V 2A power supply with external DC 12V power adapter. When apply AC power supply, user will have one DC 12V 1A output for signal extender. Standard delivery will be packed with AC power cord only.

  • Input: 2x HDMI 2.0b, 1x DP1.2a, 1x VGA
  • HDCP: HDMI V2.2/V1.4, DP: HDCP: V1.3
  • Max. input resolution: 4096x2160 @60fps,7680*1200 @30Hz.
  • Output: 2x HDMI up to 2048x1080/60 & WUXGA
  • 1x HDMI 2.0 loop out ports for multiple unit
    cascade & daisy chain connection
  • Geometry alignment up to 9x5 grid points via remote controller and 17x17 points via PC Tool.
  • Maximum geometry adjustment range is up to 1200 pixels in both horizontal and vertical directions.
  • Edge blending at 4 edges up to H=1920 pixel, V=1200 pixels with independent RGB gamma correction and 9 areas black level uplift.
  • Support Corner Wall adjustment in H&V at flexible location with the same image scaling factor.
  • Support Linearity Grid Line adjustment for quick H&V line position alignment.
  • Embedded full function video wall function for image split, cropping and overlap pixel setting.
  • Support non-VESA standard input timings
  • Selectable output up to 2048*1080 60Hz.
  • 4:4:4 Chroma sampling, 30 Color bits, 12-bit RGB gamma CLUT
  • Support sRGB & xvYCC color processing & 8/10/12-bit deep color
  • System settings can be stored and backup.
  • Selectable grid pattern size from 8-120 pixels in H&V direction. Default is 32*32 pixels.
  • Selectable grid pattern color and with optional transparency to see background image.
  • Flexible aspect ratio adjustment in each edge up to +_ 1800 pixels cropping range.
  • 50Hz in/out & frame rate conversion.
  • 10-bit processor, 3:2/2:2 cadence, low angle smooth algorithm, high quality scaling engine
  • 3D motion adaptive de-interlace
  • Frame lock for multiple channel synchronized outputs
  • Phase lock and free-run modes for quicker mode change
  • High Dynamic Range (HDR) support: SMPTE ST-2084, SMPTE ST-2086
  • Individual color and white balance adjustment in each output channel.
  • Individual 90/180/270 rotation, flip, cropping, scaling & color adjustment in each channel
  • 90/270 degree rotation and flip only available under 4k/30Hz input resolution.
  • Embedded HDMI & SPDIF audio outputs
  • Selectable and programmable EDID
  • ESD Protection: ±8kV (Air-gap discharge), ±4kV (Contact discharge)
  • Dual power supply in G802. User can use either AC 100-240V or DC 12V power supply. When use AC power
    supply, there is a DC 12V 1A output for signal extender.
  • Power consumption: max. 11w
  • Working environment: 45〫C, 10-90% RH
  • Control: IR, RS232, WebGui & PC tool for USB & Ethernet
  • Dimensions: 440mm*180mm*45mm, Weight: 2.1kg
  • CE/FCC/RoHS/Green Certified
  • 2 Year Warranty, paid extension available up to 5 years
