Martin - MAC Ultra Performance

The MAC Ultra Performance has raised the bar for extremely bright moving lights and features benchmark output across the zoom range, a true next generation framing system, higher definition optics and astoundingly low noise levels.

Built to support the biggest live events, this powerful workhorse is based on the brand new 1150 W, 6000 K proprietary LED light engine and the fixture pushes an incredible 46,500 lumens in projection. The 50,000+ hour light engine also provides high resolution dimming, strobing and Martin’s unique Animotion™ effect.

A 1:7 zoom-range and precision focus-control is provided from the refined optical system. The extensive feature package includes uniform color mixing, variable CTO, additional color and spectral correction filters, Martin’s innovative Extended Framing system, two layers of rotating gobos, full function animation wheel, iris, frost and prism effects, and truly responsive and accurate pan and tilt. And, these features are all packed into a compact, sturdy and legendary Martin design.

The MAC Ultra Performance is perfect for a wide range of concert and touring productions but is equally applicable for noise-sensitive broadcast and theater stage lighting applications. Simply put, when it comes to workhorse fixtures that push the boundaries of output and performance execution, the MAC Ultra Performance stands boldly in a class all its own.

Feature Highlights


The MAC Ultra Performance produces an incredible 46,500 projection lumens. With our tailor-made light engine and optics designed as a single unified system, MAC Ultra excels on keeping output across the zoom range. With high luminous flux and intensity at narrow zoom angles, MAC Ultra delivers the punch needed for the longest throws and highest trims - no stage or venue is too big for MAC Ultra Performance.


Our proprietary LED light engine is the foundation for MAC Ultra visual quality, built around the very latest technology to meet ever-stretched performance requirements. Our engine not only provides impressive metrics, but most importantly is more pleasing to the human eye. With higher red content and 6000 K color temperature for better daylight balance, it delivers richer, more vivid colors and more natural skin-tones.


MAC Ultra was designed to not only deliver best-in-class output and quality in its first hour of use, but throughout its product life. The minimum LED lifetime exceeds 50,000 hours and the engine delivers over 90 percent of its initial output after 20,000 hours of full output. In real-world applications, this equals rock-solid performance and stability. Our engineering team has achieved these results through a sophisticated cooling system and by never driving the 1680 W LED package at more than 70 percent of its maximum rating. This combination ensures visual excellence and peace of mind throughout the life of the product.


With remarkably higher projection resolution and definition, incredible sharpness across the field and enhanced contrast, the MAC Ultra Performance features our most impressive projection system ever. The 1:7 zoom system with accurate focus capability maintains a flat field. The beam stays bright at the edge for higher visual impact and white tones and colors stay more consistent across the beam. Thanks to this optical design, MAC Ultra delivers excellent morphing from one gobo plane to the other and outstanding results when using framing and gobos together.


MAC Ultra Performance truly raises the bar with a next-generation framing system. It offers more flexibility, easy programming, quick response time and enhanced shutter angling. Where existing systems have no tilting of the shutter blades at the very edge of the beam and only obtain their specified tilt range when the blades are fully inserted, the Martin Extended Framing System offers fully specified shutter tilting from the very outside of the beam all the way across to the opposite side. This results in limitless, full curtain functionality and the ability to throw more light onstage. And, the MAC Ultra Performance keeps the four framing blades in just two layers, offering more even focus across all four blades.


The sophisticated MAC Ultra cooling system ensures a precise operating temperature window and sets a new standard for low acoustic levels. It’s not only ideal for a range of concert and touring productions but is equally applicable for noise-sensitive broadcast and theater stage lighting applications.


MAC Ultra features a unique and compact industrial design. Martin’s patented yoke handles provide better ergonomics and safer handling of the light. To benefit stage and set designers, all connectors and the UI are placed on the same side of the unit, leaving the opposite side free from visual distraction. Follow-spot handles are also permanently incorporated, and tool-free replacement of air-inlet filters is easier than ever to access.


  • 1150 W proprietary LED light engine
  • 84 x 20 W white LEDs
  • Minimum LED lifetime: >50,000 hours (see specs for further details)


  • Light Engine Luminous Output: 90,000 lumens
  • Fixture Luminous Output: 46,500 lumens
  • Peak Luminous Intensity: 2,600,000 cd
  • CCT: 6000 K


  • 160 mm front Lens
  • 1:7 zoom range - 7.7° - 53°
  • High resolution projection system


  • Dimmer/shutter:  0 - 100% continuous dimming, regular and random strobe and pulse effects, instant open and blackout
  • Dimming options: Choice of four dimming curves
  • Color mixing: CMY, independently variable 0 - 100%
  • Color temperature control: Variable 6000-2850 K
  • Color wheel: 6 x interchangeable dichroic filters + open (incl. Spectral Enhancement Filter),
  • indexing, continuous rotation, random color
  • Rotating gobo wheel 1: 5 x interchangeable gobos + open, indexing, continuous rotation and shake
  • Rotating gobo wheel 2: 5 x interchangeable gobos + open, indexing, continuous rotation and shake
  • Gobo Color Temperature Correction: Automatic
  • Gobo animation: Interchangeable animation wheel, indexing, continuous rotation with variable angle,
  • speed and direction
  • Frost: Variable 0 - 100%, second (heavy) frost available as optional replacement for Prism
  • Prism: 4-facet, indexing and continuous rotation
  • Iris: Variable 0 - 100%, pulse effects
  • Zoom: Motorized
  • Focus: Motorized, range varies with zoom angle, from approx. 4.5 m (14.8 ft.) to infinity
  • Framing: Rotatable framing module, +/- 83°, 4x individually controllable full curtain blades with full variable angle (+/- 30°) through the entire insertion path from 0 - 100%
  • Pan: 540°, coarse & fine control and speed
  • Tilt: 268°, coarse & fine control and speed
  • P3: Videomapping of fixture color and/or intensity with variable crossfade between DMX control and video control
  • Pre-programmed effects: Two ranges of FX, independent or synchronized/combined


  • Control Protocols: DMX, RDM, Art-Net, RDM over Art-Net, sACN and P3
  • Protocol Detection: Automatic
  • DMX Modes: One
  • DMX Channels: 48
  • 16-bit Controllable Parameters: Dimming, Color Mixing + CTC, Gobo Rotation/Indexing, Zoom, Focus, Pan and Tilt
  • Setting and Addressing: Display Menu, RDM, RDM over Art-Net or P3
  • Local User Interface: Backlit LCD Display with battery-powered operation
  • Fixture identification: User-settable ID number
  • DMX Compliance: USITT DMX512-A
  • RDM Compliance: ANSI/ESTA E1.20
  • Art-Net Compliance: Art-Net 1, 2, 3 and 4; including RDM over Art-Net
  • sACN Compliance: ANSI E1.31 - 2016
  • Martin P3 Compliance: P3 System Controller Software 5.1.0 or newer
  • DMX/RDM Transceiver: Galvanic-isolated RS-485
  • Ethernet Transceiver: 10/100Mbit (with fail-safe bypass)
  • Firmware Update: USB memory device, via DMX using Martin Companion or via Ethernet using P3 System Controller


  • Front Lens Diameter: 160 mm
  • Zoom Range: 7.7° - 53° (1:7)
  • Light Source: 84 x 20 W White LEDs in a custom Martin engine
  • Maximum Total LED Engine Power: 160 mm
  • Minimum LED lifetime: >50,000 hours (to >80% luminous output)* / >20,000 hours (to >90% luminous output) *Figure obtained under manufacturer’s test conditions


  • External Diameter: 37.5 mm +0 / -0.2 mm (1.476 in. +0 / -0.008 in.)
  • Maximum image diameter: 30 mm (1.181 in.)
  • Maximum gobo thickness: 1.1 mm (0.04 in.)
  • Material: Borofloat 33
  • Coating: Heavy matted aluminum


  • Light Engine Luminous Output: 90,000 lumens
  • Fixture Luminous Output: 46,500 lumens
  • Peak Luminous Intensity: 2,600,000 cd
  • CCT: 6000 K (+/- 250 K)
  • TM-30 Rf (IES TM-30-15 Fidelity Index): 62
  • TM-30 Rf (IES TM-30-15 Fidelity Index) with Spectral Enhancement Filter @ 5600 K: 77
  • TM-30 Rf (IES TM-30-15 Fidelity Index) with CTO @ 3200 K: 84
  • TM-30 Rf (IES TM-30-15 Fidelity Index) with Spectral Enhancement Filter and CTO @ 3200 K: 86
  • CRI (Color Rendering Index): 66
  • CRI (Color Rendering Index) with Spectral Enhancement Filter @ 5600 K: 80
  • CRI (Color Rendering Index) with CTO @ 3200 K: 86
  • CRI (Color Rendering Index) with Spectral Enhancement Filter and CTO @ 3200 K: 91
  • LED Refresh Rate: 3000 Hz


  • Sound Pressure Level (LpA) @ 1 m (default regulated fan mode, full output): 36 dB(A)
    Sound Pressure Level (LpA) @ 1 m (constant fan mode low): 32 dB(A)


  • Housing: High-impact flame-retardant thermoplastic
  • Color: Black
  • Protection rating: IP20
  • RoHS: Compliant
  • REACH: Compliant


  • Mounting points: 2 pairs of 1/4-turn points for 106 mm (4.17 in.) center-to-center omega brackets
  • Location: Dry location only, must be fastened to surface or structure
  • Orientation: Any
  • Minimum distance to combustible materials: 0.2 m (8 in.)
  • Minimum distance to illuminated surfaces: 4.75 m (15.6 ft.)


  • AC power: 200-240 V AC nominal, 50/60 Hz
    Power Supply Unit: Auto-ranging electronic switch mode
    Maximum total power consumption: 1450 W
    Maximum total current at 200 V: 8.0 A
    Maximum total current at 240 V: 6.7 A
    Power consumption, all effects static, zero light output: 100 W
    Typical half-cycle RMS inrush current at 230 V, 50 Hz: 6.7 A


  • 208 V, 60 Hz: 6.8 A, 1380 W, PF 0.99
  • 230 V, 50 Hz: 6.0 A, 1380 W, PF 0.99
  • 240 V, 50 Hz: 5.8 A, 1380 W, PF 0.99

Measurements made at nominal voltage. Allow for a deviation of +/- 10%. PF = power factor.


  • Cooling: Forced air (temperature regulated, low noise)
  • Maximum Ambient: Temperature (Ta max): 40° C
  • Minimum Ambient Temperature (Ta min): 5° C
  • Maximum surface temperature, steady state, at 40° C ambient: 85° C (185° F)
  • Total heat dissipation (calculated, +/- 10%): 4950 BTU/hr.


  • Length (head): 660 mm (26.0 in.)
  • Length (base): 468 mm (15.5 in.)
  • Width (across yoke): 520 mm (20.5 in.)
  • Width (base): 312 mm (12.3 in.)
  • Height (head straight up): 864 mm (34.1 in.)
  • Height (maximum): 876 mm (34.5 in.)
  • Minimum center-to-center distance in side-by-side installation: 830 mm (32.7 in.)
  • Weight: 44.0 kg (97.0 lbs.)
