Absen - PL4.8W Lite

Absen - PL4.8W Lite

Outdoor LED Display

Front & Rear module maintenance:

Supports front & rear maintenance, easy to replace the module

Edge protection:

Away from the ground

Quick swappable Power box:

Replace in seconds with a quick relase system, Serviceable from the back without tools

One man installation:

Quick and simple to use top locks, designed for easy one man handling

Higher image quality:

Combined with grey scale coding technology that is human eye friendly, the new control system has greatly improved t he industry-common problem of losing grey scale at low brightness, to provide much more vivid image.

Waterporoof design:

IP65/54 waterproof design for outdoor products of P3.9 & P4.8mm, ultra reliable in all weather conditions

Platform design:

4 different pixel modules can be used on one frame

Ligten up and go large:

Super lightweight and twice the size, perfect for operational demands of extra large outdoor display applications.

• Pixel Pitch: 4.8
• Brightness: 4500
• Panel Dimensions: 500*500*88
• Panel Material: Die casting Aluminum
• Panel Weight: 7.8 KG
• LED Type: SMD 1921
• Module size: 250*250
• Panel resolution: 104*104
• Pixel Density: 43264
• Refresh rate: 3840
• Grayscale: 14
• Viewing Angle: 140/120
• Ingress Protection: IP65/IP54
• Power (max/ave.): 570/190
• Drive mode: 1/7
• Maximum hanging: 20
• Certification: FCC, ETL, CE, RoHS
