RGBlink - MSP204 - HDMI to SDI Convertor

MSP204 is an HDMI to SDI video converter. The converter provides an HDMI input and SDI output supporting up to 3G-SDI.

In addition there are 2 balanced analog audio input for embedding audio to HDMI. In addition an SDI loop is also provided.

MSP204 supports a wide range of resolutions including 480i, 576i, 720p, 1080i and 1080p,

Compact in size, MSP204 is convienient to use and easy to operate and configure.

Locate or install one or mulitple MSP203 together with other MSP devices in a rack using the MSP Garage.

Connectors

  • Input: 1 x HDMI - 2 x ¼in Jack
  • Output: 1 x BNC (SDI)
  • Communication: 1 x USB mini-B
  • Power: 2.5mm Cylindrical

Performance

  • Input Resolutions: HDMI: 480i | 576i | 720p@50/59.94/60 | 1080i@50/59.94/60 | 1080p@23.98/24/25/29.97/50/59.94/60
  • Output Resolutions: SDI: 480i | 576i | 720p@50/59.94/60 | 1080i@50/59.94/60 | 1080p@23.98/24/25/29.97/50/59.94/60
  • Standards Supported: SDI: ITU-R BT656 | ITU-R BT.601 | SMPTE 259M | SMPTE 292 | SMPTE297
  • HDMI: 1.3

Power

  • Input Voltage: 12V DC (visa universal plug pack)
  • Max Power: 1.5A

Environmental

  • Work Temperature: 0°C~40°C
  • Relative Humidity: 10%~85%

Physical

  • Net Weight: 0.2kg
  • Net Size: 98mmx93mmx24mm
More Information
Condition New
Brand RGBlink
