Martin - Exterior Dot-HP (Clear front, RGB)

Martin - Exterior Dot-HP (Clear front, RGB)

Martin by HARMAN Exterior Dot-HP is a bright, outdoor-rated dot designed to create media facades or perimeter lighting on large buildings and structures for long-distance viewing. This high-performance exterior LED dot for large venues allows for long fixture runs with variable pixel pitches for flexible designs. A creative tool for lighting designers, the Exterior Dot-HP is available in two versions – RGB color mixing or cool white – with a number of front designs for a variety of unique looks. It is driven by the Martin P3 System Controller family for easy setup and video display. The Exterior Dot-HP is also compatible with RDM/DMX for smaller setups.

Key features:

• High-intensity calibrated video dot
• Rugged IP66 housing for permanent outdoor installations
• Easy setup and long cable runs for clean installation
• 100 lumen per dot calibrated
• Available in clear front, diffuser dome and directional lens variants
• RGB or cold white LED engine
• Flexible mounting system allows for customized solutions
• Local integral in-built diagnostics tool
• High-quality 16-bit per color image processing technology
• Pixel-level brightness and color calibration for optimal image quality
• P3/RDM/DMX controllable (automatic protocol detection)
• Intuitive mapping and addressing via P3 System Controller
• Combined power/data input over single cable
• Supported by integrated power and data processor (P3 PowerPort 1500 or P3 PowerPort 1000 IP) and simple cabling system

*Dots in the Exterior Dot-HP range are supplied in cardboard boxes containing multiples of 9 dots. Remaining dots (and orders that consist of less than 9 dots total) are supplied in individual packs.

Physical:

• Diameter: 72 mm (2.9 in.)
• Height with clear front: 34 mm (1.4 in.)
• Height with dome front: 49 mm (2 in.)
• Height with directional front: 43 mm (1.7 in.)
• Weight, clear front and dome front models: 300 g (0.7 lbs.)
• Weight, directional front models: 350 g (0.8 lbs.)

Control and programming:

• Control options: Martin P3™ System Controller via Martin P3™ PowerPort 1500, Martin P3™ PowerPort 1000 IP and/or RDM/DMX
• Control modes: RGB (RGB variants), white intensity (CW variants), basic
• Control resolution: 16-bit (P3) or 8-bit (DMX) control of each color
• Protocol detection: Automatic
• Setting and addressing: Martin P3™ System controller or RDM-compliant
• DMX controller
• DMX channels: 3/10Calibration: Color and intensity for each Dot
• DMX compliance: USITT DMX512-ARDM compliance: ANSI/ESTA E1.20
• Firmware update: Via Martin P3™ System Controller

Control/User interface:

• Device status: Multi-color visual indication
• Device test and reset: Magnetic button to call up fixture status and test fixture

Optics:

• Options:Clear Front
• Dome Front
• Directional Front (TIR lens)
• LED manufacturer, Exterior Dot-HP RGB: Osram
• LED manufacturer, Exterior Dot-HP CW: Seoul
• Minimum LED lifetime: 50,000 hours (to >70% luminous output)*

*Figure obtained under manufacturer’s test conditions

Photometric data:

• Color resolution: 16 bits per color (48 bit per pixel)
• Dot pitch: 72 mm - 500 mm (center-to-center)
• Color Temperature:Cool white (CW): 6700K±300K
• RGB: 2.000 – 10.000 K (adjustable via P3 or DMX)

Viewing angle:

• Clear front: 103° x 103° (half-peak)
• Dome front: 125° x 125° (half-peak)
• Directional front: 22° x 22° (half-peak)

RGB Dots:

Total output, calibrated mode

• Clear front: 90 lumens, 36 cd
• Dome front: 62 lumens, 18 cd
• Directional front: 72 lumens, 270 cd

Total output, non-calibrated mode

• Clear front: 120 lumens, 48 cd
• Dome front: 80 lumens, 24 cd
• Directional front: 96 lumens, 360 cd

Cool White Dots:

Total output, calibrated mode

• Clear front: 160 lumens, 62 cd
• Dome front: 110 lumens, 32 cd
• Directional front: 120 lumens, 590 cd

Total output, non-calibrated mode

• Clear front: 210 lumens, 82 cd
• Dome front: 142 lumens, 41 cd
• Directional front: 160 lumens, 775 cd

Video processing:

• Brightness control
• Gamma correction and control
• Color temperature control
• Color space control
• Calibration processing
• Synchronization

Signal protocol:

• P3 (via Martin P3™ PowerPort) or RDM/DMX

Construction:

• Color: Electrostatic powder-coated (custom colors available by special order) (custom colors available on project basis)
• Base: Cast aluminum
• Protection rating: IP66
• Impact resistance: IK05
• Corrosion resistance: C5-M (very high corrosivity / marine, ISO 12944)
• RoHS compliant

Installation:

• Mounting points: Direct surface mount, optional mounting plate or optional mounting profile
• Orientation: Any

Connections:

• Power and data input: 6-pin custom (BBD) IP66-rated
• Power and data thru: 6-pin custom (BBD) IP66-rated
• Hot-pluggable

Electrical:

• Nominal input voltage: 48 VDC +/- 4%
• Power supply options: Martin P3™ PowerPort 1500, P3™ PowerPort 1000 IP, Martin™ IP66 PSU or generic 48 VDC PSU
• Typical total power consumption, calibrated mode: 5 W at full intensity, full white
• Typical total power consumption, uncalibrated mode: 7 W at full intensity, full whiteSurge protection: 4 KV

Thermal:

• Cooling: Convection
• Maximum ambient temperature (Ta max.): 55° C (131° F)
• Minimum ambient temperature (Ta min.): -20° C (-4° F)
• Total heat dissipation (calculated, +/- 10%): 20 BTU/hr.

Approvals:

• EU safety: EN 60950-1, EN 60950-22
• EU EMC: EN 55024, EN 55032 (Class A), EN 61000-3-2, EN 61000-3-3
• US safety: UL 60950-1, UL 60950-22
• US EMC: FCC Part 15 Class A
• Canadian safety: CSA C22.2 No. 60950-1, No. 60950-22
• Canadian EMC: ICES-003 Class A
• Australia/NZ: RCM
